Details

Big Grip Dead end

Material used

Big-Grip dead-ends are made of material compatible with the strand to which they are applied



Application and inspection

Ensure the correct size fitting is used. For detailed method of installation refer to application

instructions. Big Grip dead-ends must only be used on the size and type of strand for which they are designed. Big Grip dead-ends should not be re-used after original installation.



Production Characteristics

Cross-over marks: indicate starting point for application

Color code: assists in identification of strands size.

Identification label: Shows catalogue number and strand diameter range.

l Lay direction: Must be same as that of the outer layer of the strand to which it is applied



BG Series - Galvanized Strand Wire

Model

Strand

Approx Length(In.)

Color code

RHS (Lbs.)

% of Strands RBS

Size (in.)

Construction

Actual dia. (in.)

BG-C115

1/2

7W or 19W

0.459 or 0.500

49

Red

26900

100

BG-C116

9/16

7W or 19W

0.564 or 0.565

55

Yellow

35000

100

BG-C111

5/8

7W or 19W

0.621 or 0.625

64

Black

42400(7W)

40200 (19W)

100

BG-C112

3/4

19W

0.750

76

Orange

58300

100

BG-C113

7/8

19W

0.885

90

Green

79700

100

BG-C114

1

19W or 37W

1.000 or 1.001

125

Blue

104500(19W)

92430 (37W)

100



90

Left-hand lay direction

For use on: Extra High Strength Siemens Martin, High Strength Utilities Grade

RHS: Rated Holding Strength

RBS: Rated Breaking Strength

BG-A1xx: A Class G/S wire,  BG-B1xx: B Class G/S wire,  BG-C1xx: C Class G/S wire.


ABG Series - Aluminum Clad Steel Wire


Model

Strand

Approx Length(In.)

Color code

RHS (Lbs.)

% of Strands RBS

Dia Min. (in.)

Dia Max. (in.)

Size

ABG-1568

0.475

0.494

7#6

42

Blue

22730

100

ABG-1569

0.495

0.515

19#10

44

Green

27190

100

ABG-1570

0.516

0.536

25M

47

Red

25000

100

ABG-1571

0.537

0.555

7#5

48

Yellow

27030

100

ABG-1572

0.556

0.570

--

49

Blue

33330


ABG-1573

0.571

0.591

19#9

50

Orange

34290

100

ABG-1574

0.592

0.612

--

50

Green

34450

100

ABG-1575

0.613

0.635

--

54

Yellow

45000

100

ABG-1576

0.636

0.661

19#8

56

Black

43240

100

ABG-1577

0.662

0.686

19*0.1363

59

Blue

47400

100

ABG-1578

0.687

0.712

--

61

Red

54200


ABG-1579

0.713

0.741

19#7

37#10

63

Black

51730

50300

100

95

ABG-1580

0.742

0.772

19*0.1499

71

Yellow

54300

100

Left-hand lay direction

RHS: Rated Holding Strength

RBS: Rated Breaking Strength
