Anchoring clamp
Material: Nylon plus fibre glass
| Type | Conductor cross-section (mm2) |
| STA | 2*(10-16) |
| STB | 2*(16-25) |
| STC | 4*(16-25) |
| STD | 1*(16-70) |
| STE | 2*(6-16) |
| LA1 | 4*(16-25) |
| LA2 | 2*(6-16) |
| PA2.1 | 1*(16-25) |
| PA1500 | 1*(50-70) |
| PA2000 | 1*(70-120) |
Product property：
The plastic anchoring clamp is suitable for insulated low-voltage ABC cable. It is also suitable for multiple conductors.Easy installation and perfect insulated function. It is in accordance with NFC 33-042.
NFC 33-042
