Fiber optic pigtails provide a fast way to make communication devices in the field. They are designed, manufactured and tested according to protocol and performance dictated by the industrial standards, which will meet your most stringent mechanical and performance specifications.
Fiber optic pigtails provide a fast way to make communication devices in the field. They are designed, manufactured and tested according to protocol and performance dictated by the industrial standards, which will meet your most stringent mechanical and performance specifications.
For item#2 and 25
Model: Pigtail LC/UPC SM - G652D 0.9mm-1M
Item | Description | Requirements1 |
1 | Material | LSZH/PVC |
2 | Size | 900um tight buffer |
3 | Connectors | LC/UPC |
4 | Standard | To conform to ITU-T. G652D |
5 | Type | Single mode |
6 | Insertion loss | 0.15dB (max) |
7 | Return loss | 55/56dB |
8 | Mechanical endurance | 500 matings |
9 | Drop | Drop height 1m, 5drops |
10 | Operating temperature | -20degC to +50 degC |
